Product Overview

The STIHL MS 170 is the perfect lightweight chainsaw for homeowners seeking a great value. Compact, lightweight with just the right amount of power, the MS 170 makes quick work of trimming or cutting small trees, fallen limbs after a storm and other tasks around the yard.

Anti-vibration system

The Intellicarb compensating carburetor is designed to automatically adjust the air/fuel ratio when the air filter becomes restricted or partially clogged and maintains the engines correct RPM

Intellicarb uses air from the clean side of the air filter to control the diaphragm and flow of fuel

The Ematic guide bar, when used with STIHL Oilomatic saw chain, will provide proper lubrication and less oil consumption than conventional methods

The air filter becomes dirty and less air is available for the carburetor, the Intellicarb system adjusts the fuel flow to compensate for the decrease in air flow

Specifications

• Brand Name:STIHL
• Product Type: Chainsaw
• Antivibration Handle: Yes
• Bar Length: 16 inch
• Brand Name: STIHL
• CARB Compliant: Yes
• CSA LIsted: No
• Case Included: No
• Chain Brake: Yes
• Chainsaw Type: Chainsaw
• Engine Displacement: 30.1 cubic centimetre
• Engine Type: 2-Cycle
• Maximum Cutting Diameter: 17 inch
• Model Number: MS 170
• Start Type: Pull Start
• Tension Adjustment Type: Manual
• Warranty: 1 Year
• Powered By: Gas
• Product Grade: Professional

Features

Made in America

•

• A majority of STIHL products sold in America are made in America of U.S. and global materials.

Anti-Vibration System

•

• STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.

IntelliCarb™ Compensating Carburetor

•

• The IntelliCarb™ Compensating Carburetor is designed to automatically adjust the air/fuel ratio when the air filter becomes restricted or partially clogged and maintains the engine’s correct RPM. IntelliCarb™ uses air from the clean side of the air filter to control the diaphragm and flow of fuel. As the air filter becomes dirty and less air is available for the carburetor, the IntelliCarb™ system adjusts the fuel flow to compensate for the decrease in air flow. This is in contrast to typical carburetors that utilize this air from the “dirty” side of the air box.

Ematic™ Lubrication System

•

• The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%.

Width	Weight	Height	Length
0 Inch	0 Gram	0 Inch	0 Inch
