Description:

Feature:

• ENGINE OPTIONS: BRIGGS, KAWASAKI & KOHLER
• AVAILABLE DECK SIZES: 48", 54" & 60"
• PATENTED EZ-RIDE® SYSTEM
• INDUSTRY-LEADING 3/8˝ STEEL FRONT FORKS
• 3/16˝ OR 7-GAUGE ALL STEEL, FORMED AND WELDED DECK WITH REINFORCED EDGES
• DUAL HYDRO-GEAR 3200 SERIES INTEGRATED DRIVE SYSTEMS
• PATENTED INDEPENDENT FRONT SUSPENSION
• I-BEAM FRONT RAILS
• HEAVY-GAUGE, ALL-STEEL, ALL-WELDED FRAME
• PEER, MAINTENANCE-FREE SPINDLES
• SEAT LIFTS FOR EASY MAINTENANCE AND CLEANING
• ADJUSTABLE STEERING ARMS
• ELECTRIC PTO
• COMFORT SEAT

Specification:

• MAVERICK ENGINE OPTIONS
• KOHLER
• 48"/54"/60" - 747CC, 25HP AIR-COOLED CONFIDANT ZT740
• KAWASAKI
• 48"/54"/60" - 726CC, 24HP AIR-COOLED FS730V
• BRIGGS
• 54"/60" - 810CC, 27HP AIR-COOLED CXI27
• MAVERICK DIMENSIONS
• CUTTING WIDTHS
• 48"/54"/60"
• WEIGHT
• 48" - 957 LBS. | 54" - 1,005 LBS. | 60" - 1,031 LBS.
• HEIGHT / LENGTH
• 47"/80"
• CHUTE UP / CHUTE DOWN WIDTH
• 48" - 54"/61" | 54" - 58"/67" | 60" - 64"/73"
• MAVERICK FEATURES
• SUSPENSION
• E-Z RIDE® PATENTED COMPRESSION REAR SUSPENSION WITH INDEPENDENT FRONT SUSPENSION RAILS
• TRANSMISSION
• 3200 HYDRO-GEAR® 10CC INTEGRATED TRANSAXLE
• DECK THICKNESS
• 3/16" OR 7-GAUGE THICK SOLID STEEL
• CUTTING HEIGHT
• 1.5" - 4.5" WITH DECK HEIGHT CONTROL SYSTEM
• LIFT & HEIGHT ADJUSTMENT
• FOOT-ASSIST MANUAL LIFT WITH DIAL-STYLE HEIGHT ADJUSTMENT. OPTIONAL ELECTRIC LIFT.
• REAR TIRES / FRONT TIRES
• 48" - 23X9-12 REAPER® / 13X6.5-6 SMOOTH
• 54"/60" - 23X11-12 REAPER® / 13X6.5-6 SMOOTH
• FUEL
• 6.5 GALLONS, UNLEADED GASOLINE
• GROUND SPEED (FORWARD)
• UP TO 9 MPH
